Filter Vessels, Water Separator HDF-CS Series
Filter/Water Separator
HDF-CS Series
The two-stage HDF horizontal filter vessels with excellent particulate filtration and high water removal properties at high flow rates enable use in various diesel applications and in particular in fields with poor fuel quality.
By maintaining absolute diesel cleanliness, end users can significantly increase the life of critical wear components, minimising downtime and maximising profitability.
Benefits
- Designed for high flow and high volume diesel fuel filtration
- Excellent particulate and high water removal properties
- Maximum protection for downstream sensitive injection system and fuel pumps
- Ensure fuel meet cleanliness specifications
Technical Data
- Design and construction: AD2000 or ASME-Code
- Flow rates (maximum): Up to 7950 lpm (2100 USgpm)
- Flow rates (recommended): Up to 4770 lpm (1260 USgpm)
Standard Design
- Material: Carbon steel (other version on request)
- Interior: Epoxy coating
- Exterior: Prime coated
- Cover seal: NBR (Buna-N)
- All FAUDI Diesel Filter Vessels are sized according to customer requirements & site specific conditions
